    Outdoor Distribution Four Port Dual Band Antenna Polarization Vertical Polarization

    Ask Lasest Price
    Supply Ability : 2000000PCS/Year
    Delivery Time : Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays
    Payment Terms : LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
    • Product Details
    • Company Profile

    Outdoor Distribution Four Port Dual Band Antenna Polarization Vertical Polarization

    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    Features:

    ★Wide frequency band, wide coverage
    ★PIM optimized design.
    ★Ideal for all kind of DAS applications.
    ★Low insertion loss.
    ★High power handling.
    ★Small size, Low weight.
    ★Good stability.

    Specifications:

    Electrical Specifications
    Frequency RangeMHz698-960 & 1710-27003300-4000
    GaindBi6.0±16.5±16.5±1
    Polarization2x±45°2x±45°2x±45°
    Beam widthHorizontaldeg757068
    Vertical707060
    VSWR≤2.1≤1.8≤1.8
    IsolationdB>15>20>23
    PIM, 3rd Order, 2 x 20 W,dBc-150
    Input Power per Port, maximumwatts50
    Mechanical Specifications
    Dimensions, HxWxDmm300x280x130mm
    Weight, without Mounting Kitkg/
    Radome Material and ColorABS, White, RAL9003
    Mounting KitPanel, via hole (standard)
    Connector Type and LocationDIN-F emale×4
    Operational TemperatureoC-55 to +60
    Operational Humidity%< 95
    Operating Humidity95%RH
    Operational / Max Wind Speed150 / 200km/h
    Wind Load @150km/h
    Frontal / Lateral / Rearside
    214 / 60 /214N
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna 885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna



    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna
    885-960MHz/1710-2675MHz Outdoor Distribution Four Port Dual Band Antenna


    All our products can satisfy :
    1: Customized Color (Black, Red, Grey, Golded,etc.)
    2: Used in IBS/DAS/Public Safety/ Small Cell /Public Network / Private Network
    3: Trial order accepted to prove our superior quality
    4: OEM/ODM available .
    5: Product Lead: delivery within 4 weeks for mass production
    6: Unbeatable price to support you win the bid

    All our products category :
    RF Antenna , RF combiner, Power Splitter , Directional Coupler, Hybrid Coupler, RF Loads, RF Attenuator , Cable Assembly , RF Jumper Cable, RF Coaxial Cable , Cable clamp , etc.
    We owe one-stop supply chain capability , you can get the lowest price for your DAS/IBS project .

    Customers we served :
    HUAWEI, ZTE, ERICSSON and their branch abroad, CHINA MOBILE, CHINA UNICOM, CHINA TELECOM and ROSENBERGER, RSF, etc.

    Cooperate Once, Replace Never !
